| Application | 식수, 급수, 표층수, 지하수 |
| Parameter | Chloroform, Dichloro- Monobromo Methane, Chloro-dibromomethane, Bromoform, Total THMs, Total TOC (ppb) related to THMs |
| Measurement Range | THM GC-PID-TID 1...500 ppb THM THM GC-TID 1...200 ppb THM |
| Accuracy | 5 % |
| Repeatability | 5 % |
| Time Resolution | 15...30 min |
| Operation Mode | Online, Manual |
수처리
반도체
제약
Features
|
Specification
Principle | Gas Chromatography Analysis |
Detector | Photo Ionization Detector (PID) |
| Measurement Range | THM GC-PID-TID 1...500 ppb THM |
Limit of Detection | 1 ppb for each Component |
Accuracy | 5 % |
Repeatability | 5 % |
Sampling Channels | Max 4 Channels |
Volume per Sample | < 250 ml |
Measurement Time | 15…30 min |
Sample Pressure | Max 10 bar (145 psi) |
Operating Mode | - Automatic/Selectable Sequence or Manual Single Measurements |
Operating Environment | 0...90 % Relative Humidity, Non-Condensing |
Analog Output | 4-20mA – 4 Channels |
Serial Interface | RS 485 |
Electrical Supply | 115...230 VAC, 50/60 Hz (Single Phase L1, N, PE) |
Power Consumption | 0.5 kW |
Dimentions | 656 x 653 x 1800 mm |
Weight | 80 kg |
