| Application | 발전소, 반도체, 석유 및 가스, 제지, 케미칼 |
| Parameter | Ammonia |
| Measurement Range | 0...5000 µg/L (ppb) |
| Limit of Detection | 0.5 µg/L (ppb) |
| Calibration | Automated Calibration |
| Temperature Range | 5...45°C |
| Accuracy | ≤ 1% or ± 1 µg/L (range 0...500 ppb)/ ≤ 5% (range 500...5000 ppb) |
| Pressure | 0.2 - 5.0 bar (2.9 - 72.5 psi) |
반도체
발전소
제지
석유 및 가스
케미칼
Features
Specification
Parameter | Ammonia |
Principle | Heteropoly-Molybdenum Blue Colorimetric Method |
Measurement Range | 0...5000 µg/L (ppb) |
Limit of Detection | 0.5 µg/L (ppb) |
Temperature Range | 5°C...45°C (41°F...113°F) |
Accuracy | ≤ 1% or ± 1 µg/L (0...500 ppb) |
Pressure | 0.2...5.0 bar (2.9...72.5 psi) |
Repeatability | ≤ 1% or ± 0.6 µg/L (ppb) |
Resolution | 0.01 µg/L for reading < 10 µg/L (ppb) |
Interval | 10 min (Fast Mode) or 15 min (Standard Mode) |
Calibration | Automated Calibration |
Channel | 2, 4 or 6 Channel Sequencer (Optional) |
Output | 2 isolated 0/4...20 mA, max load 900 Ω |
Dimension | 406 mm x 678 mm x 320 mm |
Weight | 22.5 kg (49.5 lbs) |
Communication | RS485, MODBUS RTU/TCP/IP, USB Drive PROFIBUS (Optional) |
Electrical Supply | 100...240 VAC, 100 W, 50/60 Hz |
