| Application | 반도체, 식수, 수처리, 식품 |
| Parameter | Fluoride |
| Measurement Range | 10 ppb...200 ppm |
| Limit of Detection | 10 ppb |
| Temperature Range | -10...120˚C |
| Accuracy | ±10% or 10 ppb± (0.5 mV + 0.1%)± 0.5°C |
| Pressure | 0.55...6.89 bar (8...100 psig) |
수처리
식품
반도체
식수
Features
Specification
Parameter | Fluoride |
Principle | Ion Selective Electrode (ISE) |
Measurement Range | 10 ppb...200 ppm |
Limit of Detection | 10 ppb |
Temperature Range | -10...120˚C |
Accuracy | ±10% or 10 ppb |
Pressure | 0.55...6.89 bar (8...100 psig) |
Resolution | 2, 3 or 4 digits |
Calibration | Double Known Addition, Offline calibration |
Channel | 1 |
Output | 0...20 mA; 4...20 mA |
Display | Custom Backlit LCD with Temperature, Concentration, mV, Error Codes and Menu Driven Prompts |
Dimension | Physical size Electronics: 144 x 144 x 187 mm |
Electrical Supply | 100...120 V, 200 mA or 200...240 V, 100mA, 50/60 Hz |
