제품 소개

Applications

• Water Softening
• Zeolite Softener Effluent
• Blending Applications

Parameter

Calcium Hardness

Measurement Range

25 ppb...500 ppm/ ± 1999.9 mV

Limit of Detection

25 ppb

Temperature Range

-10...120˚C

Accuracy

± 10 % or 10 ppb
± (0.5 mV + 0.1%)
± 0.5˚C

Pressure

0.55 bar...6.89 bar (8...100 psig)

Resolution

1, 2 or 3 Digits

Calibration

Double Known Addition (DKA), Offline Calibration

Channel

1 Channel

Output

0...20 mA; 4...20 mA

Display

Custom Backlit LCD with Temperature, Concentration, mV, Error Codes and Menu Driven Prompts

Dimension

Physical size Electronics: 144 x 144 x 187 mm
Entire system: 650 x 450 x 270 mm

Power supply/requirement

100...120V 200mA / 200...240V 100mA; 50-60 Hz AC
