Parameter	pH	ORP	Conductivity	Resistivity	Toroidal Conductivity	Dissolved Oxygen	Ozone
Measurement Range	0...14 pH	±2100 mV	0...5000 μS/cm	0...18.2 MΩ·cm	0...2 S/cm	0...40 ppm	0...10 ppm
Resolution	0.01 pH	0.1 mV	4.5 sig figs	4.5 sig figs	1 μS/cm	0.01 ppm	0.01 ppm
Accuracy	0.1 % of Reading						2 %
Key Features	Replaceable Reference Salt Bridge	Replaceable Reference Salt Bridge	Titanium or 316 SS 2-Electrode	Titanium 2-Electrode	Ideal for CIP	Easy to Replace Membrane Cartridge	Easy to Replace Membrane Cartridge
Sensor Details	Standard, Low & High Temp, Pure Water, HF	Platinum or Gold	0.01, 0.1, & 1.0 Cell Constants	0.01 Cell Constant	Electrodeless	Polarographic	Polarographic
Sensor Materials	CPVC, PEEK	CPVC, PEEK	CPVC, PEEK, Titanium & 316SS	CPVC, PEEK, Titanium & 316SS	CPVC, PEEK	PEEK	PEEK
Sensor Process Connection	1 & 1½″ NPT	1 & 1½″ NPT	½, ¾ or 1″ NPT	½, ¾ or 1″ NPT	¾″ NPT	1″ NPT	1″ NPT
Application
Drinking Water	●	●	●			●	●
Wastewater	●	●	●	●	●	●	●
Industrial Water	●	●	●	●	●	●	●
